32 inch high brightness LCD open frame monitor
Size: 32 inch
Resolution: 1920*1080
Brightness: 2000 nits
Category: Open frame monitor
Model No.: RS320ENT-GD20-OP
RS320ENT-GD20-OP features:
| Item | 32.0” open frame monitor |
| Model | RS320ENT-GD30-OP |
| Screen Size | 32 inches |
| Display Area | 698.4*392.85 mm |
| Outline Dimenssion | 714.96*404.6*66.5mm |
| Panel Type | High-brightness LCD with WLED |
| Configuration | RGBW Vertical Stripe |
| Resolution | 1920*1080pixel |
| Brightness | 2000nits |
| Aspect Ratio | 16:9 |
| Constrast Ratio | 1300:1 (Typ.) (TM) |
| Response Time | 8ms (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Driver Elements | a-Si TFT-LCD |
| Surface Treatment | Antiglare (Haze 2%), Hard coating (2H) |
| Display Color | 16.7M 68% NTSC |
| Display Mode | IPS, Normally Black, Transmissive |
| Interface Type | LVDS (2 ch, 8-bit) , Connector , 51 pins |
| Input Voltage | DC24V |
| Power | 280 W |
| Weight | 12 kg |
| Backlit Lifetime | 50000hrs |
| Operating Temp. | -20°- 60°C |
| Storage Temp. | -20°- 60°C |
Open frame monitor series:
| Model name | Size (inch) | brightness | Resolution | Operating temperature |
|---|---|---|---|---|
| RS185ENT-NE10-OP | 18.5 | 1000 | 1920*1080 | 0 ~ 50 ℃ |
| RS215ENT-NE10-OP | 21.5 | 1000 | 1920*1080 | 0 ~ 50 ℃ |
| RS270ENT-NE15-OP | 27 | 1500 | 1920*1080 | 0 ~ 50 ℃ |
| RS320ENT-ND20-OP | 32 | 2000 | 1920*1080 | 0 ~ 50 ℃ |
| RS420IVN-GD30-OP | 42 | 3000 | 1920*480 | -20 ~ 70 ℃ |
| RS430ENT-ND20-OP | 43 | 2000 | 1920*1080 | 0 ~ 50 ℃ |
| RS490ENT-GD30-OP | 48.5 | 800 | 1920*1080 | -20 ~ 60 ℃ |
| RS550ENT-GD40-OP | 55 | 4000 | 1920*1080 | -20 ~ 60 ℃ |
