Size: 55 inch
Resolution: 1920*1080
Brightness: 4000 nits
Category: Wide temperature LCD panel
Model No.: RS550ENT-GD40
Panel Brand | RisingStar | Panel Model | RS550ENT-GD40 |
Panel Size | 55″ | Panel Type | a-Si TFT-LCD ,LCM |
Resolution | 1920(RGB)×1080 | Pixel Format | RGB Vertical Stripe |
Display Area | 1209.6(H)× 680.4(V) mm (A.A) | Bezel Opening | / |
Outline Size | 1242.1(H)× 718(V) × 60.3(D) mm | Surface | Hard coating(2H), Anti-glare low reflection treatment of the front polarizer (Haze 3%(Typ.)) |
Brightness | 4000 cd/m²or customized | Contrast Ratio | 1200:1 (Typ.) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | Normally Black, Transmissive |
Display Colors | 1.07B | Response Time | 8 (Typ.)(Tr+Td) ms |
Frequency | 60Hz | Supply voltage | 24V (Typ.) |
Weight | TBD (Typ./Max.) | Signal Interface | LVDS 51 pins |
Environment | Operating Temp.:-20℃~70℃; Storage Temp.:-20℃~70℃ |
Model name | Size (inch) | brightness | Resolution | Operating temperature |
---|---|---|---|---|
RS320ENT-GD20 | 32 | 2000 | 1920*1080 | -20 ~ 70 ℃ |
RS320HAN-GD30 | 32 | 3000 | 1920*1080 | -20 ~ 70 ℃ |
RS430ENT-GD30 | 43 | 3000 | 1920*1080 | -20 ~ 70 ℃ |
RS550ENT-GD30 | 55 | 3000 | 1920*1080 | -20 ~ 70 ℃ |
RS550ENT-GD40 | 55 | 4000 | 1920*1080 | -20 ~ 70 ℃ |
RS650ENT-GD35 | 65 | 3500 | 3840*2160 | -20 ~ 70 ℃ |
RS750ENT-GD40 | 75 | 4000 | 3840*2160 | -20 ~ 70 ℃ |
RS860EQL-GD40 | 86 | 4000 | 3840*2160 | -20 ~ 70 ℃ |
